| Model Type | Rede-319 | Rede-325 | Rede-625 |
| Sensor | |||
| Sensor Type | VOx Uncooled | VOx Uncooled | VOx Uncooled |
| Sensor Resolution | 384×288 | 384×288 | 640×512 |
| Pixel Pitch | 12μm | 12μm | 12μm |
| NETD | ≤20mk | ≤20mk | ≤20mk |
| Frame Frequency | 50Hz | 50Hz | 50Hz |
| Optics | |||
| Objective lens | 19mm | 25mm | 25mm |
| Angle of View | 13.8°×10.4° | 10.5°×7.9° | 17.5°×13.1° |
| Continuous Digital Zoom | 1.8X~7.2X | 2.3X~9.2X | 1.4X~11.2X |
| Eye Relief | 13mm | 13mm | 13mm |
| Diopter of Eyepiece | -7D~+2D | -7D~+2D | -7D~+2D |
| Display | |||
| Display Type | OLED | OLED | OLED |
| Resolution | 640*480 | 640*480 | 640*480 |
| Palettes | White Hot/Black Hot/Ironbow/Glowbow/Sepia/ Red Hot/Green Hot |
||
| Detection Distance | |||
| Distance（Target size 1.8x0.5m） | 1000m | 1200m | 1200m |
| Video Recorder | |||
| Video/Photo Resolution | 640*480 | ||
| Video/Photo Format | avi/jpg | ||
| Built-in Memory | 32GB | ||
| WIFI | |||
| Wireless Standard | 802.11b/g/n | ||
| Frequency | 2.4GHz | ||
| Connection Range | ≤10m | ||
| Power Supply | |||
| Output Voltage | 3~4.2V | ||
| Battery Type | 18650 Battery（Built-in) | ||
| Capacity | 3200mAh | ||
| Operating Time | ≥8hrs. | ≥8hrs. | ≥7hrs. |
| External Power Voltage | 5V | ||
| Charging Hours | ≈4hrs | ||
| Charging Temperature | 0~45℃ | ||
| Physical Characteristics | |||
| Weight | 345g | 355g | 355g |
| Length | 168mm | 171mm | 171mm |
| Environmental Characteristics | |||
| Degree of Protection, IP code | IP67 | ||
| Operating Temperature | -25℃～+50℃ | ||
| Storage Temperature | -40℃～+60℃ | ||
